Home Electric Car Charging Solution: Convenience Redefined
EU Standard
Caro Pro 黑色 main

1

Caro Pro series

AC
Caro Pro Series Home Wallbox embodies environmental responsibility by supporting PV charging & dynamic load balancing, helping reduce electricity costs, meet green objectives with smart energy use.
22kW
Home / Dealership
  • CE
  • CB 1
  • RoHS 黑
  • reach
  • EN303645
EU Standard
Saro series

1

Saro series

AC
Saro Series Home Wallbox meets homeowners’ needs with its compact design, dynamic load management system, and user-friendly app for convenient operation and maintenance.
22kW
Home / Dealership
  • CE
  • CB 1
  • RoHS 黑
  • reach
  • EN303645
EU Standard
caro series ev charger

Caro series

AC
Type 2, 1.6 OCPP, 2023 Red Dot Award winner, support solar charging, smart load balance management.
7kW/11kW
Residential / Dealership
  • CE
  • CB
  • RoHS 黑
  • UKCA
  • EN303645
US Standard
silk home wallbox

Silk series

AC
Type 1, 1.6 OCPP, UL certificated, 2023 Red Dot Award winner, support solar charging, smart load balance management.
10kW / 12kW
Residential / Dealership
  • UL
  • FCC
  • energy star
  • CSA
EU Standard
NANO EN 带电表 3

Nano series

AC
For home/commercial use, remote control, QR code/card activation, 8 safety features, optional wireless, smart load balancing.
1x22kW(2x11kW) / 1x44kW(2x22kW)
Home / Workplaces/ CPO / Retail & hospitality / Commercial parking / Fleets / Dealership
  • CE
  • CB 1
  • RoHS 黑
  • reach
EU Standard
alvis series ev charger

Alvis series

AC
Stylish, network-connected for Type 2 EVs, featuring load balancing, and ETSI EN 303 645 certified.
7kW/11kW
Residential
  • CE
  • CB
  • RoHS 黑
  • UKCA
  • EN303645
ev charger software

Software

Charge your EV with Evchargo App. Remotely track, operate, and maintain your EV with EN Plus Evchargo Cloud.

robust structure
Robust
Structure
Evchargo Cloud
Evchargo
Cloud
Business Growth
Business
Growth
Extensive Compatibility
Extensive
Compatibility

Home EV Charging Applications

Benefits of Our Home Charging Solution

01
.

Convenience:

You can charge your EV at any time, without worrying about the availability or operating hours of public charging stations.
02
.

Intelligence:

With evchargo software, you can monitor and control your charging sessions, get notifications when fully charged, and schedule sessions in advance.
03
.

Energize Your Savings

Home EV Charging can help you save money on energy costs by optimizing your charging schedule to take advantage of lower electricity rates during off-peak hours. This can result in significant savings over time, especially for frequent EV users. Moreover, Home EV Charging can monitor your energy consumption and provide insights into how you can better manage your home energy usage.

benefits of home charging solutions
03
.

Energize Your Savings

Optimize EV charging at home to save money. Use off-peak rates for lower costs and monitor energy use for efficient consumption and savings
05
.

Safe and Reliable

Home EV Charging offers smart features for remote monitoring and control via an app. Track progress, get full charge alerts, and schedule sessions.
04
.

Smart Connectivity

Offering smart features for remote monitoring and control via an app. Track progress, get full charge alerts, and schedule sessions.

Case Study

home charging solution case study

FAQs for Home EV Charging Solution

Home chargers, usually Level 2 AC chargers, are tailored for residential settings. They function by connecting to a standard 240-volt electrical supply, drawing alternating current (AC) from the grid. This AC power is then converted to the direct current (DC) required for charging an electric vehicle (EV). Typically, this AC to DC conversion takes place within the EV itself through its onboard charger.

The perks of home chargers include the convenience of overnight charging or whenever the EV is parked at home, ensuring it’s ready for daily use. Moreover, they offer long-term cost savings as they generally have lower charging rates compared to public stations.

Home chargers necessitate a standard 240-volt electrical supply, akin to what’s used for large household appliances like dryers and ovens. Level 2 home chargers typically provide output power ranging from 3.3 kW to 7.7 kW or higher, depending on the charger’s specifications and EV compatibility. This power level dictates the charging speed, with higher-powered chargers facilitating faster charging.

The time required to fully charge an electric vehicle (EV) at home varies based on factors like the EV’s battery capacity, charger’s power rating, and current state of charge.

Let’s examine estimated charging times for the Tesla Model 3 with different chargers:
Tesla Model 3 (Long Range) Battery Capacity: Approximately 82 kWh.

Charging Times:
Using a 7 kW Home Wallbox Charger (typical residential charger), it may take around 11-12 hours for a full charge from nearly empty, suitable for overnight charging.
With an 11 kW Home Wallbox Charger (providing slightly higher power), expect a full charge in approximately 7-8 hours, faster than the 7 kW charger.
Accessing a 22 kW Business Wallbox Charger (common in commercial settings) could reduce charging time to roughly 3.5-6 hours for a full charge, offering a significantly faster option.
Home chargers can be used to charge a wide range of electric vehicles (EVs). They are compatible with various types of electric vehicles, including:
  1. Battery Electric Vehicles (BEVs): These EVs run solely on electric power and have no internal combustion engine. Examples include the Tesla Model 3 and Nissan Leaf.
  2. Plug-in Hybrid Electric Vehicles (PHEVs): PHEVs have both electric and gasoline engines. They can operate in electric-only mode for a certain distance before switching to gasoline. Examples include the Toyota Prius Prime and Ford Escape PHEV.
  3. Extended-Range Electric Vehicles (EREVs): EREVs have an electric motor that drives the wheels, but they also have a gasoline generator to extend their range when the battery is depleted. The Chevrolet Volt is an example of an EREV.
  4. Hybrid Electric Vehicles (HEVs): While not typically charged externally, some HEVs have a plug for limited electric-only driving. Most HEVs use regenerative braking to charge their batteries and do not require external charging. Examples include the Toyota Prius and Honda Insight.
Yes, users can remotely monitor their charging sessions. Many electric vehicle (EV) charging stations and networks offer mobile apps or online platforms for this purpose. These features typically include:
  • Charging Status: Users can check real-time details such as charging rate, energy consumption, and estimated completion time.
  • Start and Stop: Users can remotely initiate or halt charging sessions, providing flexibility and control.
  • Payment and Billing: Users can view charging costs, payment history, and receive billing information.
  • Charging History: Access to a log of past charging sessions, including dates, times, energy consumption, and costs.
  • Notifications: Some apps send alerts about charging session progress or issues.
  • Reservation: In some cases, users can reserve charging stations in advance to ensure availability.
Remote monitoring enhances EV charging convenience, enabling users to stay informed and make informed decisions, even when away from the charging station.
To lower your EV charging costs at home, consider these two strategies: solar charging and dynamic load balancing.

Solar Charging:
Install appropriately sized solar panels based on your energy needs, including EV charging.
Utilize net metering to send surplus solar-generated electricity back to the grid and receive credits.
Invest in an EV charger compatible with solar systems to optimize solar power usage. For instance, chargers like EN Plus Alvis Series, Caro Series, or Vita Series integrate with solar inverters for efficient charging.
Schedule EV charging during peak solar production hours to maximize free solar electricity.

Dynamic Load Balancing:
Use a smart EV charger with dynamic load balancing to manage your home’s electrical load efficiently. For example, chargers equipped with this feature can intelligently distribute power, like distributing power to the EV charger while ensuring essential household loads are prioritized.
Prioritize essential household loads and allocate power to your EV charger.
Avoid peak demand charges by evenly spreading EV charging throughout the day.
Optimize energy costs by scheduling charging during off-peak hours when electricity is cheaper.

By combining solar charging with dynamic load balancing, you can minimize environmental impact and reduce EV charging costs effectively. Consulting a professional installer for tailored solutions is recommended.
